SKT-LT-003

Our main products include various types of roll forming machine, pipe processing machine, wire drawing machine, lathe and other related machines, etc.

Commodity name： SKT-LT-003

Category:

Nylon drag chain series

Email:

Shengkun.liuxu@gmail.com

WhatsApp:

+8618858689791

Get Quote

Technical documentation

Technical sheet

The centralised chip conveyor device is a combination of large-scale chip conveyor, which generally adopts chain plate chip conveyor and chain dragging to scrape out the chips along the bottom of the chip conveyor, so as to collect and convey granular metal iron chips, fine iron chips, casting iron chips and non-metallic chips, with a large conveying flow. The machine has streamline modelling, beautiful appearance, smooth chip removal, small volume, high efficiency, stable transport, safe and reliable, low noise, and overload protection function. The pitch is 31.75mm and 50.8mm for choice.

The process of machining and manufacturing will produce a large number of chips. These chips often contain a large amount of oil and cutting emulsion. Due to the fluffy chips, easy to scatter around the machine tool and the workshop channel, so it is not only difficult to clean up, but also seriously pollute the workshop environment. The traditional solution is to clean up the chips manually and finally converge the chips into a large chip box, which is regularly lifted to the car by an overhead crane and transported out. This method is a large workload, waste of manpower, and occupy the production overhead crane, easy to conflict with the production, and the workshop chip storage area will take up the effective use of the workshop area, affecting the logistics of the workshop, but also cause difficulties in the management. With the development of the production of CNC machine tools are widely used, the workpiece processing efficiency has been greatly improved, but the corresponding research for the machine tool chip removal is relatively lagging behind, and now most of the research on chip removal is only for a single machine tool, rarely involved in the design of the entire workshop chip removal system. For this reason, our company designs a set of solutions for the whole workshop chip removal system.

产品描述

Suitable for 40mm or less of cable.

Basic technical data

Pitch=30.3mm,link per meter=33,length of chain=S/2+K,S=stroke.K=π.R+"safety ration"

R	75	100	125	150	200
H	205	255	305	355	455
D	133	158	183	208	258
K	303	394	455	545	697

H:=H+55mm( 0.2kg/0.25m)Actual mounting height:H,=H+55mm

Cable Chain No.	Hi	Bi	Ha	Ba	Styles	Bending radius R	Bracket type and parameters
							Applicable bracket type		Bore diameter φ1	hole distance						Bracket No.
							Applicable bracket type		Bore diameter φ1	A	B	C	D	E	F	Bracket No.
JY45Q.1.25W	45	25	55	49	Q. W	75,100, 125,150,200		F-Q	5.5	22.5	37	70	30	12.5	49	JY45Q.1.25W-FJT
JY45Q.1.38W	45	38	55	62	Q. W			F-Q	5.5	22.5	50	70	30	12.5	62	JY45Q.1.38W-FJT
JY45Q.1.50W	45	50	55	74	Q. W			F-Q	5.5	22.5	62	70	30	12.5	74	JY45Q.1.50W-FJT
JY45Q.1.57W	45	57	55	81	Q. W			F-Q	5.5	22.5	69	70	30	12.5	81	JY45Q.1.57W-FJT
JY45Q.1.75W	45	75	55	99	Q. W			F-Q	5.5	22.5	87	70	30	12.5	99	JY45Q.1.75W-FJT
JY45Q.1.77W	45	77	55	101	Q. W			F-Q	5.5	22.5	89	70	30	12.5	101	JY45Q.1.77W-FJT
JY45Q.1.100W	45	100	55	124	Q. W			F-Q	5.5	22.5	112	70	30	12.5	124	JY45Q.1.100W-FJT
JY45Q.1.103W	45	103	55	127	Q. W			F-Q	5.5	22.5	115	70	30	12.5	127	JY45Q.1.103W-FJT
JY45Q.1.125W	45	125	55	149	Q. W			F-Q	5.5	22.5	137	70	30	12.5	149	JY45Q.1.125W-FJT

Note:Q.W Bridge type exterior opening,X: oblique bracket,Different serial number indicates the difference rank type of fixing holes

Fix bracket type and parameters(See table)

Keywords:

Drag Chain，Chip Conveyor
